Printhead Card U for Toshiba 636M
Printhead Manufacturer
Riso
Printhead Family
CF1/CF1L/CF1XL (U)
Overview
The HIB-TT-636-M from GIS is a printhead card designed to provide communications between the RISO Technologies Corporation CF1/CF1L/CF1XL printheads and the GIS Printhead Card Managers (PHCM-C2/PHCM-C8-3).
Printhead Variants Supported
CF1, CF1L, CF1XL, CF1B, CF1BL, CF1BXL, CF1BD3, CF1LBD3, CF1XLBD3
Number of Printheads Driven from One Module
4
GIS Product Code & Identifier
1200246 - HIB-TT-636M
Print Modes
| Binary | |
| Greyscale |
Dimensions
| Length | 145mm |
| Width | 100mm |
| Depth | 15mm |
| Weight | 105g |
| PC to PHCM Connection Length | up to 5m |
| PHCM to PHC Connection Length | up to 10m |
| PHC to Printhead Connection Length | 300mm |
Control
| Printhead Heater | |
| Thermal Protection |
Monitoring
| Board Temperature | |
| Printhead Temperature |
Connectivity
| Power Supply | |
| Number of Connectors Required to Drive Printhead | 2 |
